SIQ series
Standard 27.5" Size
FHD/4K Pixel to Pixel Resolutions
4 IN 1 Integrated Packaging
IMD Integrated Packaging
About SIQ series
| Item | SIQ 2.6 | SIQ 2.9 | SIQ 3.9 | SIQ 4.8 |
| Pixel Pitch | 2.604 mm | 2.976 mm | 3.91 mm | 4.81 mm |
| Max Brightness Calibrated | 1000 nits (black) | 1000 nits (black) | 1000 nits (black) | 800 nits (black) |
| Panel Dimension | 1000 x 250 x 60 mm | 1000 x 250 x 60 mm | 1000 x 250 x 60 mm | 1000 x 250 x 60 mm |
| Panel Resolution ( H x V ) | 384 x 96 | 336 x 84 | 256 x 64 | 208 x 52 |
| Frame Material | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy | Diecasting Aluminum Alloy |
| Weight Per Panel | 4.5 kg | 4.5 kg | 4.5 kg | 4.5 kg |
| Power Consumption Max / Average | 500 W / 250 W Per ㎡ | 500 W / 250 W Per ㎡ | 500 W / 250 W Per ㎡ | 600 W / 300 W Per ㎡ |
| Transparency | Solid | Solid | Solid | Solid |
| Serviceability | Front | Front | Front | Front |
| Curving (Concave & Convex) | Custom 45° | Custom 45° | Custom 45° | Custom 45° |
| SMD Configuration | SMD2121 Black | SMD2121 Black | SMD2121 Black | SMD2121 Black |
| Physical Density | 147,456 Pixels / ㎡ | 112,896 Pixels / ㎡ | 65,536 Pixels / ㎡ | 43,264 Pixels / ㎡ |
| Viewing Angle ( H / V) | 160° / 140° | 160° / 140° | 160° / 140° | 160° / 140° |
| Refresh Rate | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz |
| Gray Scale | 14 bit | 14 bit | 14 bit | 14 bit |
| Scan Ratio | 1/32 | 1/28 | 1/16 | 1/13 |
| Operational Temp / Humidity | - 20° ~ 45°C / 10-90% RH | - 20° ~ 45°C / 10-90% RH | - 20° ~ 45°C / 10-90% RH | - 20° ~ 45°C / 10-90% RH |
| Storage Temp / Humidity | - 40° ~ 60°C / 10-90% RH | - 40° ~ 60°C / 10-90% RH | - 40° ~ 60°C / 10-90% RH | - 40° ~ 60°C / 10-90% RH |
| IP Rating (Front / Rear) | IP30 / IP30 Indoor | IP30 / IP30 Indoor | IP30 / IP30 Indoor | IP30 / IP30 Indoor |
*Note: The specifications are for reference, actual values may vary.No Data
Standard 16:9 Size
Pixel to Pixel 4K&FHD Resolutions
G.A.LED Common Cathode Technology
G.A.LED common cathode technology improves brightness with better heat dissipation
High brightness high contrast with perfect performance
Others
SIQ series
Creative Installation
Customized cut-edge panel, able to connect into creative shape like triangle and square, help create a memorable and effective LED display project.
Front Maintenance
Primarily convenience and accessibility for maintenance purposes, modules and components can be accessed and serviced from the front side, without needing to access the rear of the display. Front maintenance is a practical solution that enhances the usability and reliability of indoor fixed installation LED displays.
